Nikon V1 with 10mm 2.8 lens

Digital camera with interchangeable lenses

Nikon 1 mount

Approx. 2.7 x lens focal length (35 mm format equivalent); Nikon CX format

10.1 million

13.2 mm x 8.8 mm CMOS sensor

Image sensor cleaning

Still images (still image and Smart Photo Selector modes, aspect ratio 3 : 2)

• 3,872 x 2,592
• 2,896 x 1,944
• 1,936 x 1,296

Still images (movie mode, aspect ratio 16 : 9)

• 3,840 x 2,160 (1080/60i)
• 1,920 x 1,080 (1080/30p)
• 1,280 x 720 (720/60p)

Still images (Motion Snapshot mode, aspect ratio 16 : 9)

• 3,840 x 2,160

• NEF (RAW): 12-bit, compressed
• JPEG: JPEG-Baseline compliant with fine (approx. 1 : 4), normal (approx. 1 : 8), or basic (approx. 1 : 16)compression
• NEF (RAW) + JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats

Standard, Neutral, Vivid, Monochrome, Portrait, Landscape; selected Picture Control can be modified; storage for custom Picture Controls

SD (Secure Digital), SDHC, and SDXC memory cards

DCF (Design Rule for Camera File System) 2.0, DPOF (Digital Print Order Format), Exif (Exchangeable Image File Format for Digital Still Cameras) 2.3, PictBridge

0.47-in., approx. 1440k-dot color TFT LCD viewfinder with diopter control and brightness adjustment

Approx. 100% horizontal and 100% vertical

17mm (-1.0m-1; from center surface of viewfinder eyepiece lens)

-3 – +1m-1

Camera switches to viewfinder display when it detects that viewfinder is in use

still image (3 : 2), Smart Photo Selector (3 : 2),
movie (HD 16 : 9, slow motion 8 : 3), Motion Snapshot (16 : 9)

1 NIKKOR lenses for 1 mount

Electronically-controlled vertical-travel focal-plane mechanical shutter; electronic shutter

• Mechanical shutter : 1/4,000-30s in steps of 1/3 EV; Bulb; Time (requires optional ML-L3 remote control)
• Electronic shutter : 1/16,000-30s in steps of 1/3 EV; Bulb; Time (requires optional ML-L3 remote control)

• Mechanical shutter: Synchronizes with shutter at X=1/250s or slower
• Electronic shutter: Synchronizes with shutter at X=1/60s or slower

• Single frame, continuous
• Mechanical, Electronic, Electronic (Hi)
• Self-timer, delayed remote, quick-response remote, interval timer shooting

• Electronic (Hi): Approx. 10, 30, or 60 fps
• Other modes: Up to 5 fps (single AF or manual focus, S Shutter-priority auto or M Manual exposure mode, shutter speed 1/250s or faster, and other settings at default values)

2s, 5s, 10s

Delayed remote (2s); quick-response remote

TTL metering using image sensor

• Matrix
• Center-weighted : Meters 4.5 mm circle in center of frame
• Spot : Meters 2 mm circle centered on selected focus area

Programmed auto with flexible program; shutter priority auto; aperture-priority auto; manual;scene auto selector

-3 – +3 EV in increments of 1/3 EV

Luminosity locked at metered value with AE-L/AF-L button

ISO 100-3200 in steps of 1 EV. Can also be set to approx. 1 EV (ISO 6400 equivalent ) above ISO 3200 ; auto ISO sensitivity control (ISO 100-3200, 100-800, 100-400 ) available

On, Off

Hybrid autofocus (phase detection /contrast detect AF); AF-assist illuminator

• Autofocus (AF): Single AF (AF-S); continuous AF (AF-C); auto AF-S/AF-C selection (AF-A); fulltime AF (AF-F)
• Manual focus (MF)

Single-point, auto-area, subject tracking

• Single-point AF: 135 focus areas
• Auto-area AF: 41 focus areas

Focus can be locked by pressing shutter-release button halfway (single AF) or by pressing A (AE-L/AF-L) button

On, Off

i-TTL flash control using image sensor available with optional SB-N5 flash unit

Fill flash, slow sync, red-eye reduction, slow sync with red-eye reduction, rear-curtain sync, rear curtain with slow sync

-3 – +1 EV in increments of 1/3 EV

Lights when optional flash unit is fully charged

Auto, incandescent, fluorescent, direct sunlight, flash, cloudy, shade, preset manual, all except preset manual with fine tuning

TTL metering using image sensor

• Matrix
• Center-weighted: Meters 4.5mm circle in center of frame
• Spot : Meters 2mm circle centered on selected focus area

HD movies

• 1,920 x 1,080/60i (59.94 fields/s *)
• 1,920 x 1,080/30p (29.97 fps)
• 1,280 x 720/60p (59.94 fps)

Slow-motion movies

• 640 x 240/400 fps (plays at 30p/29.97 fps)
• 320 x 120/1,200 fps (plays at 30p/29.97 fps)

Movies recorded in still image mode

• 1,072 x 720/60p(59.94fps)

Motion Snapshot

• 1,920 x 1,080/60p(59.94fps)(plays at 24p/23.976fps)

1080/60i(20 minutes),1080/30p(20 minutes),720/60p(29 minutes)

MOV

H.264/MPEG-4 Advanced Video Coding

AAC

Built-in or optional external ME-1 stereo microphone;sensitivity adjustable

7.5 cm/3-in., approx. 921k-dot, TFT LCD with brightness adjustment

Full-frame and thumbnail (4, 9, or 72 images or calendar) playback with playback zoom, movie playback, slide show, histogram display, auto image rotation, and rating option

Hi-Speed USB

NTSC, PAL

Type C mini-pin HDMI connector

Used for designated accessories

Stereo mini-pin jack (3.5mm diameter)

Arabic, Chinese (Simplified and Traditional),Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Indonesian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Spanish, Swedish,Thai, Turkish, Ukrainian

One rechargeable Li-ion EN-EL15 battery

EH-5b AC adapter; requires EP-5B power connector (available separately)

1/4-in. (ISO 1222)

Approx. 113 x 76 x 43.5 mm/4.4 x 3 x 1.7 in., excluding projections; thickness of body (from mount to monitor) is 36mm/1.4 in.

Approx. 383 g/13.5 oz with battery and memory card but without body cap; approx. 294 g/10.4 oz (camera body only)

0-40 °C/+32-104 °F

Less than 85% (no condensation)

EN-EL15 rechargeable Li-ion battery MH-25, battery charger, UC-E6 USB cable, EG-CP14 audio/video cable, AN-N1000 strap, BF-N1000 body cap, BS-N1000 multi accessory port cover,ViewNX 2/Short Movie Creator CD

Approx. 400, or 350 with SB-N5
